Hot Sales!integral construction hydraulic whipstock for oil well

China Hot  Sales!integral construction hydraulic whipstock for oil well supplier

Large Image :  Hot Sales!integral construction hydraulic whipstock for oil well

Product Details:

Place of Origin: China
Brand Name: Gardener
Model Number: DXQY

Payment & Shipping Terms:

Minimum Order Quantity: ONE SET
Price: See TYPE
Packaging Details: Firmed plywood box
Delivery Time: 30days according to type
Payment Terms: 30% downpayment by T/T and balance before delivery
others: We can send enginner to assist you!
Contact Now
Detailed Product Description

Integral construction hydraulic whipstock

The exploitation of many oil fields has reached the mid-final stage.The oil well recovery and the accident wells increased gradually.The technology of window cutting sidetracking,as a main method to solve these problems,has received wide application.The conventional whipstock fenestration needs two operations,whipstock and fenestration,which are complex and expensive.However,integral type whipstock realizes the two operations at one time.so it shortens the construction period and save the cost.

The integral construction hydraulic whipstock made by our company has lots of advantages,such as easy operating,firm sealing and short window cutting time and so on.

The integral construction hydraulic whipstock is divided into two parts including whipstock  and window cutting milling cone.

1.Whipstock

Whipstock adopts hydraulic sealing which is firm and easy to operate.The inclined plane is arc-like and receives super hardening treatment.The milling cone coincides highly with the inclined plane when window cutting.The more perfect self-locking mechanism adopts axial and circumferential methods which greatly improve the tool reliability.

2.Window cutting milling cone

Window cutting milling cone  complete with window cutting work in pipe together with whipstock.Design,tool shape,cutting edge angle and alloy block selection are optimized.Tje window cutting milling cone assembles window cutting and fixing as integrality.The design improves the construction speed and shortens the working period.



And after buying our products,if you need,we will send one engineer to help you to operate the equipment.

We can help you to finish the work sooner.When all tools are well prepared,within 7~10days,window sidetracking operation will be finished.

Contact us now for more informations!
