Monel 400 Banding material and Buckles for electric submersible pumping system

Minimum Order Quantity :	1 pc	Packaging Details :	reel
Delivery Time :	10~30days	Payment Terms :	T/T

Place of Origin:	CHINA

Detail Information
Material:	Stainless Steel And Monel 400

Product Description

Banding material and Buckles

Characteristic:
Excellent corrosion resistance in hydrofluoric acid and fluorine media.
Excellent cossosion resistance to hydrogen sulfide(HS) concentrated lye.

Use:
Thin strips are widely used in metal armouring belts for submersible electric pumps and submarine cables.

Chemical composition(wt%)

Alloy	Ni	Cu	Mn	Fe	C
Monel 400(UNS NO4400)	≥63.0	32	1.0	2.0	≤0.3

Mechanical properties-Age-Hardened( Rod.Forgings)

Alloy	Condition	Max.section Thickness. in(min)	Tensile strength in(min) бb		Yield strength 0.2%offset min б 0.2		Elongation δ % ≥	Ro ckwell hardness (B scal) ≥
Alloy	Condition	Max.section Thickness. in(min)	Ksi	Mpa	Ksi	Mpa	Elongation δ % ≥	Ro ckwell hardness (B scal) ≥
Monel 400 (UNS NO 4400) (Band)	Hot-worked and age-hardened	0.001(0.02) to 0.02(0.05) incl	70	485	28	195	35.0	V:68-90
Monel 400 (UNS NO 4400) (Band)	Cold-worked and age-hardened	0.001(0.02) to 0.02(0.05) incl	100	690	90	620	2.0	V:≥89
