1.184in~1.187in Monel K500 Alloy Pump Shaft for Electric Submersible Pumping equipment

Minimum Order Quantity : 10pcs Price : according to size,
Packaging Details : bubble +iron box Delivery Time : 30~35days
Payment Terms : T/T
Place of Origin: CHINA,DONGYING Brand Name: GARDENER
Certification: ISO Model Number: all sizes

Detail Information
Material: Inconel 718 And Monel K500 Size: 0.394in ~1.575in
Machining Ability: Yes,Spline End And Keyway

Product Description

1.184in~1.187in Monel K500 Alloy Pump Shaft for Electric Submersible Pumping equipment





Standard pump shaft of Gardener are machined from Monel K-500 material which provides excellent mechanical strength in normal conditions.

Special extra high strength material Inconel 718 is avaible for special applications.



This modular construction concept provides for the optimal selection of hydraulic flow and head combinations to suit any range of well requirements and can produce fluids from depths of up to 13.000ft(3.960m)





Our spec.:

0.394"-0.62" 0.62"-1.184" 1.184"-1.575"



Min.Tensile Strength ksi(Mpa):

170(1171) 160(1102) 150(1034)



Min.Yield Strength ksi(Mpa):

130(895) 130(895)

120(826)



Min.Elongation %

20 20 20



Max.Hardness HRC

42 42 42



Steel Grade Supply Status
UNS N05500 Cold working +Aging treatment



Chemical Composition

Grade Element Ni＋Co Cu Al Ti Mn Fe Si C S
UNS N05500

Min.value

Max.Value

63.0

-

27.0

33.0

2.30

3.15

0.35

0.85

-

1.5

-

2.0

-

0.5

-

0.18

-

0.010



Mechanical Property and Hardness at the indoor temperature

Grade Status

Diameter

mm

Tensile strength

Min.Value

N/mm2

Yield Strength

Bias value 0.2%

Min.Value

N/mm2

Enlongation

2inch or 4D

Min.Value

%

 Hardness

Brinell Hardness

3000kg

Min.Value

Rockwell Hardness C

Min.Value
UNS N05500 Cold working +aging treatment 10.0～25.4 1 000 760 15.0 300 32
＞25.4～40.0 965 690 17.0 280 29



Mechanical Property of UNS N07718

Enlongation lasting 690MPa

Hardness

HB
Temperature

σ0.2

MPa

 σb MPa

δ

%

ψ

%

τ

h

δ5

%
20℃ ≥1030 ≥1280 ≥12 ≥15     ≥346
650℃ ―― ≥1000 ≥12 ≥15 ≥25 ≥5



More informations,please contact  cathyshenpeng@gmail.com
