DC Tubing Encapsulation Cable with Tinned copper stranded conductor,F46 Insulation ,316L tube ,detective cable

Minimum Order Quantity : according to material and requirements Price : $2~10/meter
Packaging Details : reel Delivery Time : 10000m/30days
Payment Terms : T/T Supply Ability : according to qty
Place of Origin: CHINA Brand Name: GARDENER
Certification: ISO9001 Model Number: 16AWG/18AWG

Detail Information

Material: 316/316L/alloy 825 Or According To Client's Requirements Conductor: Tinned Copper Stranded Or One Copper Wire ,or According To Client's Requirement
Wall Thickness Of Steel Tube: 0.028" And 0.035" Tube Diameter: 6.35mm/4.0mm/3.5mm/3.2mm Etc.according To Clients' Requirements
Working Temperature: - 40°C To 150°C Cable O.D.: 11X11mm Or No Encapsulation
Purpose: Detective Cable Color Of Cable: Yellow

Product Description

DC Tubing Encapsulation Cable-TEC

can be used in harsh downhole environment



Tubing Encapsulation cable uses welded stainless steel and nickel alloy tube to protect electrical and optical components from the pressure and corrosive effects of the downhole environment.Polymeric encapsulation provides additional mechanical protection.

DGOE Tubing encapsulated conductor Cable are used to monitor, provide power and transmit signals in a downhole application.

Standard encapsulation sizes(11mmx11mm square and flatpack and multiple tube construction)are available to meet almost any downhole requirements.Composite cables utilizing various combinations of electrical and optical components are available to match specific downhole needs.



Please contact cathyshenpeng@gmail.com for more informations.





DC Tubing Encapsulation Cable with Tinned copper stranded conductor,F46 Insulation ,316L tube ,detective cable 0



**18 AWG 7X0.39mm

    FEP insulation

    Polypropylene filler

    316L/Alloy 825tube wallthickness 0.71mm

    Yellow square profile 11mmx11mm



**16AWG 7X0.49mm

   FEP insulation

   Polypropylene filler

   316L/Alloy 825tube wallthickness 0.89mm

   Yellow square profile 11mmx11mm



** Tube O.D. can be 3.2mm  3.5mm  4.0mm  6.35mm or we can make it according to client's requirements.



DC Tubing Encapsulation Cable with Tinned copper stranded conductor,F46 Insulation ,316L tube ,detective cable 1



DC Tubing Encapsulation Cable with Tinned copper stranded conductor,F46 Insulation ,316L tube ,detective cable 2

DC Tubing Encapsulation Cable with Tinned copper stranded conductor,F46 Insulation ,316L tube ,detective cable 3DC Tubing Encapsulation Cable with Tinned copper stranded conductor,F46 Insulation ,316L tube ,detective cable 4
