0.993-0.995 inch Inconel alloy Pump shaft of oil electric submersible pump-China manufacturer
0.993-0.995 inch Inconel alloy Pump shaft of oil electric submersible pump-China manufacturer
Contact Now

0.993-0.995 inch Inconel alloy Pump shaft of oil electric submersible pump-China manufacturer

Minimum Order Quantity : 20sets Price : according to drawing
Packaging Details : PLYWOOD BOX or according to clients requirements Delivery Time : 10~45DAYS
Payment Terms : T/T Supply Ability : 10,000pcs
Place of Origin: CHINA Brand Name: GARDENER
Certification: ISO9001 Model Number: 1.184in~1.187in

Detail Information
Type: Splined Shaft Material: Monel K500 ,Inconel 718
USAGE: Oil Electric SUBMERSIBLE PUMP

Product Description

0.993-0.995 inch Inconel alloy Pump shaft of oil electric submersible pump-China manufacturer



Standard pump shaft of Gardener are machined from Monel K-500 material which provides excellent mechanical strength in normal conditions.

Special extra high strength material Inconel 718 is avaible for special applications.



This modular construction concept provides for the optimal selection of hydraulic flow and head combinations to suit any range of well requirements and can produce fluids from depths of up to 13.000ft(3.960m)





Our spec.:

0.394"-0.62" 0.62"-1.184" 1.184"-1.575"



Min.Tensile Strength ksi(Mpa):

170(1171) 160(1102) 150(1034)



Min.Yield Strength ksi(Mpa):

130(895) 130(895) 120(826)



Min.Elongation %

20 20 20



Max.Hardness HRC

42 42 42




Table 4:Chemical Composition

Grade Element Ni＋Co Cu Al Ti Mn Fe Si C S
UNS N05500

Min.value

Max.Value

63.0

-

27.0

33.0

2.30

3.15

0.35

0.85

-

1.5

-

2.0

-

0.5

-

0.18

-

0.010



Table 5:Mechanical Property and Hardness at the indoor temperature

Grade Status

Diameter

mm

Tensile strength

Min.Value

N/mm2

Yield Strength

Bias value 0.2%

Min.Value

N/mm2

Enlongation

2inch or 4D

Min.Value

%

 Hardness

Brinell Hardness

3000kg

Min.Value

Rockwell Hardness C

Min.Value
UNS N05500 Cold working +aging treatment 10.0～25.4 1 000 760 15.0 300 32
＞25.4～40.0 965 690 17.0 280 29
