Downhole Gauge for ESP Equipment
Downhole Gauge for ESP Equipment
Contact Now

Downhole Gauge for ESP Equipment

Minimum Order Quantity : 1SET Packaging Details : Plywood box
Payment Terms : T/T
Place of Origin: CHINA Brand Name: GARDENER

Detail Information
Size: 450 375 350 Well Temperature: 150°C
Pressure Rating: 6500/1000 Psi Body Material: AISI 420

Product Description

Downhole Gauge

Size 450 375 350
Outside Diameter, inches 4.5 3.75 3.5
Length, inches 19.5 19.5 19.5
Pressure Rating, Psi 6500/1000
Well Temperature, DegC 150
Voltage Rating, Volts 5000
Body Material AISI420
Seals Aflas&Viton





Specification

  Rang Accuracy Resolution
Intake Pressure, Psi 5800 ±5 0.1
Discharge Pressure, Psi 5800 ±5 0.1
Intake Temperature, DegC 150 ±1 0.1
Discharge Temperature, DegC 150 ±1 0.1
Motor Temperature, DegC 400 ±2 0.1
Vibration, g 15 ±0.1
Current Leakage, mA 30 ±0.05



If you have any requirement,please kindly send email to cathy@goodespumps.com
