High Voltage Driver

Product Description

High Voltage Driver

Power Unit

Use 3-9 Power Unit for each phase, create 4N+1 step PWM wave, Y point connection, output 3-11KV directly.

New design, less weight, richer interface

Innovation for semi-seal structure. Film capacitor to protect circuit to avoid high voltage breakdown

Control System

Based on high-speed ARM, DSP, FPGA smart controller
Magnetic flux closed-loop control, optimized overlapping PWM control are adopted to achieve high-quality sinusoidal voltage and current output.

Air-force cool system

High quality centrifugal fan, huge volume air, ling runlife, high reliability.

HMI

High Quality HMI, many ports and easy to communicate with other equipment

Module Design

Module design, enhance compatibility and replacement
